High Efficiency A2 Size Digital UV Flatbed Printer TX800 Printhead Inkjet Printers for Phone Case Plastic & Acrylic Printing

High Efficiency A2 Size Digital UV Flatbed Printer TX800 Printhead Inkjet Printers for Phone Case Plastic & Acrylic Printing

  • High Efficiency A2 Size Digital UV Flatbed Printer TX800 Printhead Inkjet Printers for Phone Case Plastic & Acrylic Printing
  • High Efficiency A2 Size Digital UV Flatbed Printer TX800 Printhead Inkjet Printers for Phone Case Plastic & Acrylic Printing
  • High Efficiency A2 Size Digital UV Flatbed Printer TX800 Printhead Inkjet Printers for Phone Case Plastic & Acrylic Printing
  • High Efficiency A2 Size Digital UV Flatbed Printer TX800 Printhead Inkjet Printers for Phone Case Plastic & Acrylic Printing
  • High Efficiency A2 Size Digital UV Flatbed Printer TX800 Printhead Inkjet Printers for Phone Case Plastic & Acrylic Printing
  • High Efficiency A2 Size Digital UV Flatbed Printer TX800 Printhead Inkjet Printers for Phone Case Plastic & Acrylic Printing
  • High Efficiency A2 Size Digital UV Flatbed Printer TX800 Printhead Inkjet Printers for Phone Case Plastic & Acrylic Printing
High Efficiency A2 Size Digital UV Flatbed Printer TX800 Printhead Inkjet Printers for Phone Case Plastic & Acrylic Printing
Product Details:
Place of Origin: Guangdong, China
Brand Name: bheng
Contact Now
Detailed Product Description
Type: Inkjet Printer, Flatbed Printer Condition: New
Plate Type: Flatbed Printer Usage: Paper Printer, Label Printer, Card Printer, Tube Printer, Bill Printer, Cloths Printer
Automatic Grade: Automatic Color & Page: Multicolor
Voltage: 220V Dimensions(l*w*h): 970*1010*560cm
Weight: 90 Warranty: 1 Year
Ink Type: UV Ink Print Head: Tx800, Tx800
Ink Colors: CMYK+White+varnish Printing Size: 40*60cm
Max. Printing Height: 15cm For Standared (higher Can Be Customized) RIP Software: Ultraprint/maintop/photoprint
Key Selling Points: High-accuracy Maximum Resolution: 720*4320 Dpi
Warranty: 13 Months

Specifications
High Efficiency A2 Size Digital UV Flatbed Printer TX800 Printhead Inkjet Printers for Phone Case Plastic & Acrylic Printing 0
Product Name
UV Flatbed printer
Print Head
DX8 printhead
printhead number
1pc/2pcs
Speed
A3: 60seconds/page. A4: 70 seconds/page
Maximum Resolution
720*4320 dpi
Ink
W W K C M Y 4 COLOR +WHITE+VARNISH
printing material
Glass ,Tile,PP,Acylic board,Wood,stone,,Metal,Leather and so on
Max Printing heigh
15cm for standared (20cm for special order)
Rip software
ultraprint/photoprint/maintop
Machine Dimension
970mm*1010mm*560mm
Package Dimension
1140mm*1090mm*760mm
UV lamp
2 UV LED LAMP For water coolling
machine weight
Net.90kg/Gross.130kg
picture mode
PSD/TIFF/BMP/EPS/JPG
High Efficiency A2 Size Digital UV Flatbed Printer TX800 Printhead Inkjet Printers for Phone Case Plastic & Acrylic Printing 2
High Efficiency A2 Size Digital UV Flatbed Printer TX800 Printhead Inkjet Printers for Phone Case Plastic & Acrylic Printing 4
High Efficiency A2 Size Digital UV Flatbed Printer TX800 Printhead Inkjet Printers for Phone Case Plastic & Acrylic Printing 6
High Efficiency A2 Size Digital UV Flatbed Printer TX800 Printhead Inkjet Printers for Phone Case Plastic & Acrylic Printing 8
High Efficiency A2 Size Digital UV Flatbed Printer TX800 Printhead Inkjet Printers for Phone Case Plastic & Acrylic Printing 10
High Efficiency A2 Size Digital UV Flatbed Printer TX800 Printhead Inkjet Printers for Phone Case Plastic & Acrylic Printing 12
High Efficiency A2 Size Digital UV Flatbed Printer TX800 Printhead Inkjet Printers for Phone Case Plastic & Acrylic Printing 14
High Efficiency A2 Size Digital UV Flatbed Printer TX800 Printhead Inkjet Printers for Phone Case Plastic & Acrylic Printing 16

FAQ

1.How many basic colors does the printer uses?
Four colors, CMYK: cyan, magenta, yellow and black,White or Varnish?

2.Do you needa flat surface for the wall printer to move along the wall ?
No need for very flat walls, our wall printers print high quality pictures on uneven surfaces.

3.The process to set the printer up on site – how long does it take?
It takes only 10 minutes to assemble our?wall printer.

4.Does the machine move on the running track or does the machine move?
It is the machine that moves on the track, not the track is moving.

5.What type of ink does the printer use and where can I buy from?
The ink of the machine is custom-made, because after our adjustment, this ink is very suitable for the printing process of our machine, and the printed picture is very good. You can contact us to purchase print ink.

6.What type of files can I print with?
Support JPG, BMP, TIFF, PDF, AI, PSD, CDR, etc.

7.Durability of the ink – is it for interior or exterior applications?
The room can be kept for 10 years without fading, and the outdoor can be kept for 5 years without fading.

8.What is the print height?
The standard picture print height is 180-240cm, and the printable picture after custom vertical track is up to 350cm.

9.What materials can I print on?
Putty wall, latex paint wall, brick wall, diatom mud wall, shell powder, paper, wood. UV-wall printer can also print on?non-absorbent surfaces such as: Glass, tile, metal.

10.Any defects during the warranty period at your expense?
Non-human damage during the one-year warranty period.

11.Is it possible to enlarge a print at height? So you print out a part of the picture, then set it down again and continue. Will the photo appear to be in two parts?
Of course . You can print the stitches left and right, or you can stitch them up and down. The image printed with the feathering effect does not appear to be two parts. You can watch the video we took.
